Frameset
*Frame
Size: M , ML , L
Alpha Silver Aluminium, internal routing, chainstay disc-brake mount, rack and kickstand mount, 135x5 mm QR
*Fork
Size: M , ML , L
RockShox Judy, coil spring, preload, TurnKey lockout, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel
Max compatible fork travel 100mm (XS and S: 490mm axle-to-crown, M and up: 509mm axle-to-crown)
Wheels
Hub front Formula DC-20, alloy, 6-bolt, 5x100 mm QR
Hub rear Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
Skewer rear 152x5 mm QR
Rim Bontrager Connection, double-wall, 32-hole, 20 mm width, Presta valve
Spokes 14 g stainless steel, black
*Tyre
Size: M , ML , L , XL , XXL
Bontrager XR2 Comp, wire bead, 30 tpi, 29x2.20"
Max tyre size Frame: 29x2.20" (XS & S: 27.5x2.40"), Fork: See manufacturer
Drivetrain
Shifter Shimano Deore M4100, 10 speed
Rear derailleur Shimano Deore M5120, long cage
*Crank
Size: ML , L , XL , XXL
FSA Alpha Drive, 28T steel ring, 55 mm chainline, 175 mm length
Bottom bracket FSA, 73 mm, threaded cartridge, 122.5 mm spindle
Cassette Shimano Deore M4100, 11-46, 10-speed
Chain KMC X10, 10-speed
Pedal VP-536 nylon platform
Max. chainring size 1x: See FAQ, 2x: 36T, 3x: 42T
Components
Saddle Bontrager Arvada, steel rails, 138 mm width
*Seatpost Size: XS , S , M
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Size: ML , L , XL , XXL
Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
*Handlebar Size: S , M , ML , L , XL , XXL
Bontrager alloy, 31.8 mm, 5 mm rise, 720 mm width
Grips Bontrager XR Trail Comp, nylon lock-on
*Stem
Size: M
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length
Size: ML , L
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 80 mm length
Head set Semi-integrated, 1-1/8"
Brake Shimano MT200 hydraulic disc
*Brake rotor Size: XS , S , M , ML , L , XL , XXL
Shimano RT26, 6-bolt, 160 mm
Size: L , XL , XXL
Shimano RT26, 6-bolt, 180 mm
Brake Set Shimano MT200 hydraulic disc
Weight
Weight M - 13.47 kg/29.7 lb
Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
